2.7吋Triple-Color E-Ink Shield 三色顯示模組 for Arduino seeed原廠

NT$819 NT$760 未稅

2.7 英寸三色 E-Ink 顯示器是一個 264×176 像素的 Arduino E-Ink 顯示器擴展板，可以為每個像素顯示白色/黑色/紅色。

尚有庫存

貨號： 104030067(B6-6) 分類： , , , 標籤： , , ,
  • 商品說明

商品說明

2.7吋Triple-Color E-Ink Shield 三色顯示模組 for Arduino

E-Ink 屏幕也稱為 E-paper 屏幕，我們已經發布了多款不同尺寸的 E-Ink 屏幕，包括 Grove E-Ink module、raspberry pi E-Ink hat。現在我們向您介紹 Seeed E-Ink 家族的新成員——適用於 Arduino 的 2.7 英寸三色 E-Ink 顯示器。

2.7 英寸三色 E-Ink 顯示屏是 Arduino E-Ink 顯示屏護罩，包含 264×176 像素，每個像素可以顯示白色/黑色/紅色。該擴展板通過 SPI 接口與 Arduino 通信，並保留了 Grove I2C 接口以與其他模塊一起使用。借助比較電路，模塊實現了3.3V和5V電壓系統的自適應。

與傳統 LCD 顯示器相比，E-Ink 無需背光，因此功耗極低。並且E-Ink具有極寬的視角和極高的對比度，即使在陽光直射下也能清晰顯示。最重要的是，E-Ink 可以在沒有任何電源的情況下長時間（數週甚至數月）顯示用戶設置的圖像。多麼驚人的展示！

特徵

  • 超低功耗
  • 超寬視角
  • 高對比度

應用領域

  • 低功耗展示場景
  • 戶外展示場景
  • 工業儀表
  • 貨架標籤

硬件概述

Documents



＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝



2.7” Triple-Color E-Ink Shield for Arduino

E-Ink screen also known as E-paper screen, we have released several E-Ink screens of various sizes, including grove E-Ink module, raspberry pi E-Ink hat. Now we introduce you to the new member of the Seeed E-Ink family — the 2.7” Triple-Color E-Ink Display for Arduino.
The 2.7” Triple-Color E-Ink Display is an Arduino E-Ink display shield, which contains 264×176 pixels, and can display white/black/red for each pixel. This shield communicates with Arduino via the SPI interface and it reserves a Grove I2C interface for use with other modules. With the help of a comparison circuit, the module achieves self-adaption of the 3.3V and 5V voltage system.
Compared to traditional LCD displays, E-Ink eliminates the need for backlighting and therefore power consumption is ultra low. And the E-Ink has an extremely wide viewing angle with very high contrast so that it even can be clearly displayed in direct sunlight. On top of that, the E-Ink can display user-set images for a long time(For weeks or even months) without any power supply. What an amazing display!

Features

  • Ultra low power consumption
  • Ultra wide viewing angle
  • High contrast

Applications

  • Low power display scene
  • Outdoor display scene
  • Industrial instrument
  • Shelf label
