GP2Y0A51SK0F 夏普 紅外線測距感測器 模組 2-15 公分含線

商品說明

GP2Y0A51SK0F 夏普 紅外線測距感測器 產品介紹

GP2Y0A51SK0F 是距離測量感測器 ，由PSD（位置敏感探測器），IR-LED（紅外發射二極管）和信號處理電路的集成組合組成。 由於採用三角測量方法，物體的反射率，環境溫度和操作持續時間的變化不易受到距離檢測的影響。 該裝置輸出與檢測距離對應的電壓。 因此，該傳感器也可以用作接近傳感器

特徵

距離測量傳感器與PSD，紅外LED和信號處理電路相結合
2.測量週期短（16.5ms）
3.距離測量範圍：2至15厘米
4.體積小巧（27.0×10.8×12.0mm）
5.模擬輸出類型

夏普Gp2Y0A51Sk0F模擬距離傳感器 – 2Cm至15Cm

GP2Y0A51SK0F is a distance measuring sensor unit, composed of an integrated combination of PSD (position sensitive detector) , IR-LED (infrared emitting diode) and signal processing circuit. The variety of the reflectivity of the object, the environmental temperature and the operating duration are not influenced easily to the distance detection because of adopting the triangulation method. This device outputs the voltage corresponding to the detection distance. So this sensor can also be used as a proximity sensor

Features

1. Distance measuring sensor is united with PSD, infrared LED and signal processing circuit
2. Short measuring cycle (16.5ms)
3. Distance measuring range : 2 to 15 cm
4. Compact size (27.0 × 10.8 × 12.0mm)
5. Analog output type
