Breakout for LinkIt Smart 7688 v2 / LinkIt Smart 7688  專用 Grove 擴充板 v2.0

Breakout for LinkIt Smart 7688 集成了多個常用端口，例如以太網端口，3.5mm音頻端口和主機端口（USB Type-A連接器），用於更多外設，以及3個Grove端口為基於Grove的電子設備提供2個UART和1個I2C接口，可以節省您在智能IoT項目中進行佈線的大量工作，使您的快速原型更快。

應用思路

• IoT /網關設備
• 機器人
• 智能多媒體設備
• 智能音頻
• 教與學

特徵

• 3.5mm耳機插孔（帶麥克風），支持OMTP和CTIA
• 1個以太網連接互聯網
• 1個USB 2.0，用於更多外設
• Grove接口：2個UART，1個I2C
• 支持立體聲和AUX
• 支持錄音
• 每個立體聲端口1W輸出

查看更多linkit系列產品

Breakout for LinkIt Smart 7688 v2.0 is a Grove port integrated expansion board for LinkItTM Smart 7688 development board. This breakout board will help beginners to get started fast because it can save a lot of work and make prototyping easier through simplified wiring. It comes with USB, Ethernet, and 3.5mm Audio ports and supports serial buses like I2C, UART.

The board also integrates several frequently-used ports such as an Ethernet port, a 3.5mm audio port, and a Host port (USB Type-A Connector) for more peripherals, and along with 3 Grove ports to provide 2 UART and 1 I2C interfaces for the Grove-based electronics, it saves you a lot of work doing wirings in your smart IoT projects, makes your rapid prototyping even faster.

LinkIt Smart 7688 (a compact controller board) is an open development board, based on the OpenWrt Linux distribution, MT7688. The board is designed especially to enable the prototyping of Rich Application IoT devices for smart house.

Application Ideas

• IoT/Gateway Device
• Robotics
• Smart multimedia devices
• Smart Audio
• Teaching and learning

Features

• 3.5mm headphone Jack(with Mic) which support OMTP and CTIA
• 1 x Ethernet to connect internet
• 1 x USB 2.0 for more peripherals
• Grove interface: 2 x UART, 1 x I2C
• Stereo and AUX are supported
• Audio Recording supported
• 1W output for each stereo port

Technical Details
