Gravity: 模擬旋轉電位器 傳感器 Potentiometer Sensor V2 For Arduino DFRobot原廠

-9%

Gravity: 模擬旋轉電位器 傳感器 Potentiometer Sensor V2 For Arduino DFRobot原廠

NT$219 NT$200 未稅

這是一個Arduino兼容的多圈高精度模擬角度傳感器。它基於一個高精度的電位器,可旋轉十圈,可以精確地實現角度微小變化的互動效果,

同時它可以很方便的通過傳感器擴展版連接到您的Arduino開發板。

尚有庫存

  • 商品說明

商品說明

Gravity: 模擬旋轉電位器 傳感器 Potentiometer Sensor V2 For Arduino

普通的電位器的旋轉角度最多只有300度。所以把Arduino的5V供電分配到每1度後,精度是相當低的。如果你想製作一個角度或者模擬量精確控制的項目,最好是選擇這款精密角度傳感器。此 模擬旋轉電位器 是基於多圈精密電位器,可以旋轉10圈左右,可將電壓細分為1024份。可通過3P的連接線與傳感器擴展板結合,可以精確地實現角度微小變化的互動效果。

productImage







引腳說明



400px-DRF0058 pin.png
顏色 功能描述
黑色 電源-(GND)
紅色 電源+ (VCC)
藍色 信號線

DFRobot Arduino 旋轉電位器傳感器圖

規格

  • Arduino兼容
  • 電源要求:+3.3-5V DC
  • 外形尺寸:50x22mm
  • 信號類型:模擬信號
  • 接口模式:PH2.0-3
  • 轉動角度:3600°
  • 重量:20g



出貨清單

  • 旋轉角度感測器 x1
  • 感測器連接線 x1



Documents





=========================================================



Gravity:Analog Rotation Potentiometer Sensor V2 For Arduino

This Arduino Rotation Potentimeter Sensor is a multi-ring rotation sensor. It is based on multi-turn precision potentiometer. It can rotate upto 10 laps. The voltage can be subdivided into 1024 copies. This sensor provides a more accurate reading.

This is sensor can also be used as a simple encoder if the rotation degree is not over 3600 degree.

Gravity(sensors, shield and modules for Arduino) Interface is adapted to allow plug&play.  The IO Sensor Expansion Shield is the best match for this sound senor connecting to your Arduino. As this sensor can work at 3.3V which make it compatible with Raspberry Pi, intel edison, joule and curie.

DOCUMENTS

SHIPPING LIST

  • Rotation Potentimeter  Sensor V2x1
  • Analog Sensor Cable x1
